AWM003 and AP2620 Pre-Order start

From July 1 to July 31 Pre-Order Start for AWM003 and AP2620

Thank you for your contribution in Indigogo!

We have AWM003 is higher memory version for AWM002.
Many are asking and also the SPI version.
Below are the prices.

AWM002-SPI 15USD/pcs for SPI version less than 10 pcs.

AWM003 20USD/pcs for ordering less than 10 pcs.

AP2620 55USD/pcs for ordering less than 10 pcs

You can pay by PayPal (our account is add on the shipping fee.
Normal shipping is 10 days to 20 days by surface parcel shipping 5USD only.
If you like to be faster, we can ship by EMS and kindly send us ( your full address and telephone numbers, and we will give you a quote. Or you can check with link below.

Kindly add on 10% for total due to the exchange rate for PayPal is different with normal bank.

Thank you all and wish you like our products to develop more new devices and enjoy it!

AWM002 compared with VoCore

AsiaRF AWM002 module / VoCore Comparison Table








Below 55



25 x 35mm

 25 x 25mm


4MB/ 8MB/16M, 8MB is standard



32MB (64MB module ready)



27 x 35 mm and 94 x 74mm

Large one with all pins out for easy connected, no need soldering skill to link data cable

25 x 25 mm only


IPex connector*1(PCB antenna)

chip antenna and IPex connector


FCC/ CE (Approval done.)

FCC/ CE (In progress.)


Right away, tiny base board July, large base board right away

In June end 300 pcs Alfa versions, others August

Power Consumption

5V 250mA to 350mA, If you add on USB device, need to be added on what device you plug in.

5V 250mA to 350mA, If you add on USB device, need to be added on what device you plug in.

Extra Version

SPI version ready

Different Clock version ready (20MHz)

High SDRAM version ready (64MB, AWM003)

SPI version in test




Welcome to post your opinion here also! Thanks All.

MTK Ralink WiFi AP Router Module with low temperature less than 50 Celsuis degree

AsiaRF have launched WiFi AP Router Module with MTK Ralink IC in low temperature. Most of Router with high temperature like full speed running is 70 Celsuis degree. AsiaRF’s AWM002 full speed temperature is lessthan 60 Clesuis degree. The applications of the module are IP Camera, 3G station, Storage system, Smart TV, IPTV, STB, Media Player, Femto, XDSL, Cable Modem, Industrial PC, Ethernet Switch, Printer Server, Connected TV, Smart Phone and Portable CPE For WiMAX/LTE also for home automation.

AWAPN2403 with RT3052 is no more than 53 Celsuis degree.

Welcome to ODM or OEM.

AsiaRF Marketing team

Smallest Tiny Ralink 802.11n AP Router Module Board AWM002Portable Pocket 11n/g/b 200mW/500mW 300Mbps WiFi IP Camera AP Router AWAPN2403

The Revolution of WiFi IP Camera, 300Mbps and WiFi Repeater (WiFi Router) embedded! Extend many times of Distance and linked all IP Cameras together!

2012,  April 20. Taipei, Taiwan

The Revolution of WiFi IP Camera, Throughput 300Mbps and WiFi Repeater (WiFi Router) embedded! Extend many times of Distance and linked all IP Cameras together!

The WiFi IP Camera we saw today all were 150Mbps with PTZ function.

The revolution of IP Camera is coming. 300Mbps and WiFi Repeater embedded! You can see the WiFi IP Camera by your smart phone like Android phone and iPhone, iPAD, laptop and to link to internet in the same time.

When your devices linked with our IP camera, you can use any browser to see the image right away. No need the IP Camera software.

The default output is streaming, you can see the video by all IP camera software or surveillance software also.

The most important is the retail price is less than 99USD/pcs. Mass purchase price is less than 78USD/pcs and even lower. There are a lot of margin imagination inside!

The Revolution??? IT IS!

WiFi IP Camera and WiFi Repeater all in One!

Taipei, Taiwana

WiFi IP Camera and WiFi Repeater all in One!

What is the different of WiFi Direct IP camera and WiFi IP camera?

How to extend the WiFi distance with WiFi repeater?

Only WiFi Repeater? Can be WiFi IP camera in the same time?

Above questions are weird in some people’s mind.

No need another device to do? Really all in one?

AWAPN2403 with web camera is the device all in one.

iPhone, iPAD, Android, and any smart phone with WiFi direct slinking to access AWAPN2403, can monitor the camera in the same time with voice. Amazing right?

Most of baby monitors need two devices, one is recording camera and speaker with WiFi linking, the other is a device with screen to watch. Now you can monitor by your smart mobile phone.

The easiest way, plug and play! You can merge with your existed WiFi network by setting AP Client mode in AWAPN2403 by linked with main WiFi router. In the mean time, it is a WiFi Repeater, extend the WiFi linking area. Small RF output power and cost effective solution you can choose. Why not?

There is another simulated environment: you live alone, install AWAPN2403 with web camera in your home gate to look at inside. Before you get in, use your smart mobile phone to access the AWAPN2403 and can see inside of your home. If something wrong (like thief inside), you can avoid the accident right away.

If you have a pet in home along, you also can install this one with web camera to monitor it by internet when you are outside, in office or somewhere else by 3G linking. Only smart phone, you can see right away!

If you have more applications, welcome to post here or email to

How to link with WiFi CPE 5km far away? The answer is AWUHN2405 Super Antenna WiFi USB dongle!

The answer is AWUHN2405 Super Antenna WiFi USB dongle!

Embedded High Power RF power amplifier enhances the output and receiving sensitive also. High performance signal strength made by good EVM control.

As a WiFi Internet Service Provider, you can use this to link with WiFi Router’s (AWAPN2403) USB port as a WAN linking. Set up the hotspot base station and provide the service without CPE at all.

The cost effective is 50% off. Maintenance and rent place fee also decrease.

The best choice for ISP is AWUHN2405 and AWAPN2403.

AWUHN2405 can be indoor and outdoor using.

The same withAWUHN2405 isMegabond X and Top Cather.

AWUHN2405 is mixed indoor and outdoor applications.

Megabond X is only for indoor using.

Top Cather is the Best for car, boat and difficult environments.

WiFi USB dongle (WiFi USB LAN Card) as the WAN for the WiFi Router

What is it? Why should I have a WiFi USB dongle (WiFi USB LAN Card) as the WAN of the Router?

Normally router has the RJ45 ports, there is one marked as WAN. In the router mode, the IP address three octets are different with other LAN devices. Like WAN is 192.168.1.x, LAN is 192.168.111.x. The WAN(RJ45 port) normally is linked with switch or the other router’s LAN port. Our setting is make a WiFi USB dongle linked with WiFi Router’s USB port as a WAN linking. To avoid the radio frequency interference, the channel of the WiFi USB dongle is always different with the WiFi router.

The application is you can use a high gain WiFi USB dongle (AWUHN2405, Top Catcher, Megabond) to get the WiFi internet linking from WISP’s base station far away like 5km. Those dongles can mount in outdoor or on glass to get the signal from outside. The WiFi USB dongle’s USB cable can be 10 or even 20Meters long. The WiFi Router can broadcast the signal easily in the area we want, like dome or inner room.

Before is using a WiFi CPE to get the signal and use the CAT5 cable to link with the WiFi router. Now we replace WiFi CPE with WiFi USB dongle. Not only the cost also the application, could be the repeater easily

To see the diagram we show here. Welcome to ask us if you have any further suggestion. We would love to develop and serve you as the premium customer.

For more information of products, please check below links.
AWAPN2403AWUHN2405Top catcherMegabond.

What is the difference between real AP Router and Soft AP?

Real AP Router its CPU embedded can do more than WiFi USB dongle soft AP, like SNMP, multi SSID, VPN, multiple VLAN etc..

This is not an USB/ PCIe client in Module, this is a full AP Router full function in a module.

The World First AP Router in the market today. We are expecting many copy cat of this concept.

What advantages for WiFi AP Router Module (Mini PCIe Card)?

  1. Cost Optimized for specific application.
    Save your time cost and development cost.
  2. Flexible for draft design and application.
    You can save your time to design a new communication application in short time like 2 weeks only then finished, easy upgrade, ie. Upgrade from 11b/g/n to 11a/b/g/n, and high power etc..
  3. Time to Market, plug and play.
  4. Software transparency.
  5. Full AP Router Functions / Features.
  6. Easy Upgradable.
  7. Compact Tiny Size.
  8. Easy for Controller design.

Hope everyone like this idea and welcome to ask us more questions!

Direct WiFi IP Camera, Router Embedded!!!

WiFi Router with Camera?

IP Camera WiFi Server?

NAS with our WiFi Router?

All in one?  How to do?  What is it?

Yes, it is all in one!

AsiaRF WiFi router camera break to the current technology to down the IP Camera cost and traditional complicate installing useless IP Camera. Had you the experience to install IP camera with difficulty settings? Try our WiFi Router Camera; you will feel the convenient you never have. 1, 2, 3 and done!

View anywhere, from your iPhone, iPAD, Android Phone, Android PAD, notebook, PC can view your baby, your home and what you want to see.

Traditional WIFI does not allow you to go online and viewing the camera at the same time. AsiaRF WiFi Router Camera can seamlessly plug into your current WiFi environment.  User does not need to alternate the current WiFi environment nor does not prevent you to go online.  It can be as simple as adding a device to your network

The same time online with internet and seeing the video from Camera.

True Wireless IP Camera: WiFi router camera with mobile battery. No power cord needed.

Multi functions, not only video but audio.

There are many applications you can have. Welcome to input your application here and enjoy!

The Mystery between RF Output Power and EVM (Error Vector Measurement) for WiFi Products

Taipei, Taiwan WiFi products are marked with High power promotion, are they real High Power?

All electronic products’ or devices’ output power are counted by Watt. There are three units seen in WiFi products frequently, dBm, dBi, and EIRP. Regarding dB and Watt conversion table you can link to take a look.

Below more detail about these units:

As we know Watt is the electronic power unit.

dBm is an abbreviation for the power ratio in decibels (dB) of the measured power referenced to one milliwatt (mW). Most of vendors mark the highest output power is based on IEEE802.11b mode.

dBi is the forward gain of an antenna compared with the hypothetical isotropic antenna, which uniformly distributes energy in all directions.

EIRP (Equivalent isotropically radiated power) is the sum of output power of WiFi device and transmission loss (cable loss) and antenna’s gain. Normally you will see the amount of EIRP is big number like 10Watts or even more. Donot be scared, go to check and see, you will find out where you need to watch out for the radiation.

There is another important index called EVM (Error Vector Measurement). The lower percentage, the quality of signal transmission is better. Like 3% is better than 5%. If the EVM is higher than 5.5%, then you can see the signal index is good, but transfer the data, no. That means you cannot get homepage from internet either. Most of vendors’ QC index is 5% or 5.5%, some special high quality products is 3%, meanwhile the output power index will be a little lower. For the linking quality is also much better. From now on, if you compare the high power products, you should look at both indexes.

Hope these is helpful for your choice with High Power Products.
