WiFi Mini PCIe 11ac MTK MT7613E 5GHz High Power Half Card Module Manufacturer AWM13P-001


AWM7613 is a WiFi 11ac 5GHz High Power Far Distance Mini PCIe Module

Only Half size but High Power

Out of stock


AWM7613 is a WiFi 11ac 5GHz High Power Far Distance Mini PCIe Module.

Based on Mediatek MT7613 which is a highly integrated single chip with 5GHz 802.11 a/b/g/n/ac and provides the highest PHY rate up to 867Mbps, offering feature-rich wireless connectivity and reliable throughput from an extended distance.


  • Built with proprietary power MMICs.
  • 2.4GHz for reliable and demanding all IoT, POS, and Industrial PC applications.
  • Compatible with wireless IEEE 802.11 ac/b/g/n standard with data rates up to 867Mbps
  • Complies with wireless IEEE 802.11 ac/b/g/n standards
  • Increases wireless coverage 6 times further*
  • Supports WMM, WMM-PS (IEEE 802.11e QoS standard)
  • Supports 64/128-bit WEP, WPA (TKIP with 802.1x), WPA2 (AES with IEEE 802.1x) for high security level
  • Operating system supports for: Windows 2000/XP/Vista, Windows 7/8/9/10, MAC 10.4.x and above & Linux, Android


StandardsWireless: IEEE 802.11ac/b/g/n (2Tx2R)
mini PCI Express standard
Data RateIEEE802.11ac 867Mbps@TX/RX
IEEE802.11a/n 300Mbps@TX/RX
IEEE802.11a/g 54Mbps
IEEE802.11ac  up to 867Mbps
Output Power11a: 19dBm +/- 1.5dbm @ 54Mbps
11a/n: 18dBm+/- 1.5dbm @MCS7  HT20, 17dBm@MCS7  HT40
11ac HT20: 17+/-1.5dBm@MCS8
11ac HT40: 16+/-1.5dBm@MCS9
11ac HT80: 15+/-1.5dBm@MCS9
Receiver Sensitivity11a: -74Bm@54Mbps
11a/n: -73dBm@HT20,MCS7, -71dBm@HT40,MCS711ac: -57dBm+/-2dBm @HT20 MCS8
11ac: -63dBm+/-2dBm @HT40 MCS9
11ac: -60dBm+/-2dBm @HT80 MCS9
AntennaExternal Antenna connector (IPEX)
Frequency Range5.15GHz~5.85GHz
SoftwareSecurity: 64/128-bit WEP Encryption, WPA, WPA2
Driver: Linux
Operating VoltageDC 5V ± 5%
TemperatureOperating: 0°C ~ +50°C
Storage : -20°C ~ +70°C
HumidityOperating Humidity: 10%~90% non-condensing
Storage Humidity: 10%~90% non-condensing
WiFi High Power 11ac mini PCIe half card module AWM13P-001

Additional information

Weight0.005 kg
